Description
Overview
The Lenovo ThinkPad Ultra Docking Station provides the best docking experience for large enterprise ThinkPad customers.
The innovative side connector, designed exclusively for ThinkPad notebooks, provides a driver-free way to connect conveniently and securely to a range of USB accessories and external displays.
Also, Its rapid charging support and mirrored power button make it easy to unlock and go.
The ThinkPad Ultra Docking Station is built for today’s demanding office work, too, delivering 10 Gbps data transfer through four USB 3.1 ports. Connect up to three UHD displays for maximum productivity gains.
Also it Designed for enterprise environments, ThinkPad Ultra Docking Stations support PXE book, wake on LAN, and MAC address pass-through, simplifying asset management for IT managers.
Painstakingly designed and extensively tested, ThinkPad Ultra Docks provide seamless docking in a minimized form factor.
Key Details
- Enterprise-class universal docking for 2018 and newer T, L and X Series ThinkPad notebooks
- Innovative side connector minimizes desk space
- Intel vPro, PXE boot, Wake-on LAN, and MAC address pass-through
- Also, it Supports ThinkPad RapidCharge
- Mirrored power button and mechanical unlock
- Optional master key lock
- Moreover, Depending on many factors such as the processing capability of the host and peripheral devices, file attributes, and other factors related to system configuration and operating environments, the actual data transfer rate will be slower than 5 Gbit/s on USB 3.1 Gen 1 (USB 3.0) connectors, slower than 10 Gbit/s on USB 3.1 Gen 2 connectors, and slower than 20Gbit/s on USB 3.2 connectors.
ThinkPad ultra docking station Tech Specs
General : ThinkPad Ultra Docking Station (American Standard Plug)
Other Information
• 2 x DisplayPort 1.4
• 1 x HDMI 2.0
• 1 x VGA
• 2 x USB-C (10Gbps, 5V/3A power)
• 4 x USB 3.0 Gen 2 (10 Gbps, 1 always-on USB Charging)
• 1 x 3.5 mm Stereo/Mic Combo Port
• 1 x Gigabit Ethernet Port
• 1 x Kensington security lock slot
Supported Operating Systems : OS Independent
Compatibility : P52s, L580, L480, T580, P580p, T480s, T480, X1 Carbon Gen 6, X280
Color : Black
Max Number of External Monitors : 3
Hardware Requirements : ThinkPad Side Docking Connector
Weight : 0.81 kg (1.79 lbs)
Brand : ThinkPad
Output Power : 65 W
OS Requirements : OS Independent
Charging Port : ThinkPad Slim-tip Port
Agency Approvals : AS/NZS S-DOC, BSMI, CB, CE, EAC, EU DOC, FCC, ICES, KCC, NOM, Ukr SEPRO, UL/cUL, VCCI
Audio Ports : 1 x 3.5 mm Stereo/Mic Combo Port
USB Ports : 2 x USB-C (10 Gbps, 5V/3A power), 4 x USB 3.1 Gen 2 (10 Gbps, 1 always-on)
Video Ports : 2 x DisplayPort 1.4, 1 x HDMI 2.0, 1 x VGA
Package Type : Brown box
Warranty Period : 3 Years
Maximum Operating Temperature : 35 degrees Celsius (95 degrees Fahrenheit)
Minimum Operating Temperature : 0 degrees Celsius (32 degrees Fahrenheit)
Driver Needed : Preloaded in select ThinkPad laptops
Input Power : 135 W
Power Button : Yes
Shipment Group : ThinkPad Ultra Docking Station, ThinkPad Slim-tip 135 W AC power adapter, Power cord, 2 keys, Product information, safety and warranty poster
Warranty Type : CRU
AC Plug : American Standard Plug Type B
Refresh Rate DisplayPort: 4096 x 2160 60 Hz, DisplayPort or HDMI: 4096 x 2160 60 Hz, VGA: 2048 x 1536 85 Hz,, “Maximum resolution” refers to what can be supported by the dock. Actual resolution will vary by laptop.
In conclusion, these specs will improve your experience
