QNAP TS-464-4G NAS Storage Powered by an Intel Celeron N5105/N5095, quad-core processor ( burst up to 2.9GHz ), the TS-464 features two 2.5GbE RJ45 ports and Port Trucking for up to 5Gbps combined bandwidth.
With M.2 PCIe Gen3 and PCIe Gen 3 slots, the TS-464 provides flexibility in extending NAS functionality, allowing you to install a QM2 card for M.2 SSD caching, or Edge TPU for AI image recognition and various 10GbE/5GbE network cards.
The TS-464 comes with 4GB RAM for running light VMs and Containers, and supports multi-cloud backup, cloud storage gateways, 4K HDMI output and real-time transcoding, alongside expandable storage capacity and feature-rich apps to perform as a cost-efficient, reliable 2.5GbE NAS.
- 2.5GbE connectivity : Up to 5 Gbps transfer speeds can be achieved by setting port trucking with the two built-in 2.5GbE (2.5G/1G/100M) ports.
- M.2 SSD caching : Dual M.2 PCIe Gen 3 slots enable NVMe SSD caching or SSD storage pools for improved performance, or Edge TPU for AI image recognition.
- PCIe expandability : Install a PCIe Gen3 x2 card to expand the core functionality of the TS-464, including a Multi-Gig 10GbE/5GbE/2.5GbE network card, a QM2 card, or a USB 3.2 Gen 2 (10Gbps) card.
- License-free virtualized environment : Host multiple containerized apps to run a wide range of applications and services.
- Drives Auto-Tiering : Qtier auto-tiering technology and SSD caching enable constant storage optimization.
- 4K HDMI : 4K H.264 hardware decoding and real-time transcoding for smooth big screen multimedia experience.
CPU : Intel Celeron N5105/N5095 4-core/4-thread processor, burst up to 2.9 GHz
CPU Architecture : 64-bit x86
Graphic Processors : Intel UHD Graphics
Floating Point Unit : √
Encryption Engine : (AES-NI)
Hardware-accelerated Transcoding : √
Maximum Memory : 16 GB (2 x 8GB)
Memory Slot :
- 2 x SO-DIMM DDR4
- For dual-DIMM configuration, you must use a pair of identical DDR4 modules.
Flash Memory : 4GB (Dual boot OS protection)
Drive Bay :
- 4 x 3.5-inch SATA 6Gb/s
- The system is shipped without HDD.
Drive Compatibility :
- 3.5-inch SATA hard disk drives
- 2.5-inch SATA hard disk drives
- 2.5-inch SATA solid state drives
M.2 Slot : 2 x M.2 2280 PCIe Gen 3 x1
SSD Cache Acceleration Support : √
2.5 Gigabit Ethernet Port (2.5G/1G/100M) : 2 (2.5G/1G/100M/10M)
Wake on LAN (WOL) : √
Jumbo Frame : √
PCIe Slot :
- Slot 1: PCIe Gen 3 x2
USB 2.0 port : 2
USB 3.2 Gen 2 (10Gbps) Port : 2 x Type-A
IR Sensor : √ (Optional QNAP RM-IR004 remote control)
Form Factor : Tower
LED Indicators : Power/Status, LAN, USB, HDD1-4
Buttons : Power, USB copy, Reset
Dimensions (HxWxD) : 168 × 170 × 226 mm
Weight (Net) : 2.26 kg
Operating Temperature : 0 – 40 °C (32°F – 104°F)
Storage Temperature : -20 – 70°C (-4°F – 158°F)
Relative Humidity : 5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F)
Power Supply Unit : 90W adapter, 100-240V
Fan : 1 x 120mm, 12VDC
System Warning : Buzzer
Max. Number of Concurrent Connections (CIFS) – with Max. Memory : 1500
