QNAP TS-253E-8G NAS Storage

The QNAP TS253E NAS Storage features 2.5GbE connectivity, 8GB RAM, and M.2 slots for NVMe SSD caching to deliver high performance for applications such as surveillance systems, virtual machines, file servers or backup servers.

Description

The QNAP TS-253E-8G NAS Storage features 2.5GbE connectivity, 8GB RAM, and M.2 slots for NVMe SSD caching to deliver high performance for applications such as surveillance systems, virtual machines, file servers or backup servers.

Dual HDMI outputs also provide direct multimedia playback and robust surveillance monitoring.

QNAP will provide long-term availability and support for the TS-253E, providing a great choice for businesses requiring matching NAS models deployed in multiple locations.

Features

Dual 2.5GbE ports : 2.5 times faster network speed with existing CAT5e cables; supports port trunking to deliver up to 5Gbps.

Dual M.2 2280 PCIe slots : Attain greater NAS performance by installing M.2 2280 NVMe PCIe SSDs (sold separately) or Edge TPU.

8GB RAM onboard : System performance and multitasking is optimized with 8GB RAM.

Long-term model : The QNAP TS-253E will be available and supported by QNAP for an extended period, up to 2029.

Dual HDMI output : The dual-screen extension can be used for surveillance or 4K high-resolution video playback.

Expand storage capacity : Supports USB expansion enclosures (see the compatibility list).

QNAP TS-253E-8G NAS Storage Specs

CPU : Intel Celeron J6412 4-core/4-thread processor, burst up to 2.6 GHz

CPU Architecture : 64-bit x86

Graphic Processors : Intel UHD Graphics

Floating Point Unit : Yeas

Encryption Engine :  (AES-NI)

Hardware-accelerated Transcoding : Yeas

QNAP TS-253E-8G NAS Storage System Memory : 8 GB RAM

Maximum Memory : 8GB

Flash Memory : 4GB (Dual boot OS protection)

Drive Bay : 2 x 3.5-inch SATA 6Gb/s

Drive Compatibility :

  • 3.5-inch SATA hard disk drives
  • 2.5-inch SATA solid state drives

Hot-swappable : Yeas

QNAP TS-253E-8G NAS Storage M.2 Slot : 2 x M.2 2280 PCIe Gen 3 x2

SSD Cache Acceleration Support : Yeas

2.5 Gigabit Ethernet Port (2.5G/1G/100M) : 2 (2.5G/1G/100M/10M)

Wake on LAN (WOL) : Yeas

Jumbo Frame : Yeas

USB 2.0 port : 2

USB 3.2 Gen 2 (10Gbps) Port : 2 x Type-A

HDMI Output : 2 x HDMI 1.4b ( up to 3840 x 2160 30Hz )

Form Factor : Tower

LED Indicators : Power/Status, LAN, USB, HDD1-2

QNAP TS-253E-8G NAS Storage Buttons : Power, Reset, USB Auto Copy

Dimensions (HxWxD) : 165 × 102 × 220.6 mm

Weight (Net) : 2.57 kg

Weight (Gross) : 2.57 kg

Operating Temperature : 0 – 40 °C (32°F – 104°F)

Storage Temperature : -20 – 70°C (-4°F – 158°F)

Relative Humidity : 5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F)

Power Supply Unit : 60W/65W adapter, 100-240V

Power Consumption: HDD Sleep Mode : 20.943 W

Power Consumption: Operating Mode, Typical : 24.238 W

QNAP TS-253E-8G NAS Storage Fan : 1 x 70mm, 12VDC

System Warning : Buzzer

Kensington Security Slot : Yeas

Standard Warranty : 3

Max. Number of Concurrent Connections (CIFS) – with Max. Memory : 1500
