Description
The Intel Xeon E5-2620v3 processor is a key component of the E5-2600 processor Kits family, designed to deliver robust performance for data centers and enterprise applications. This processor is built on Intel’s 22nm manufacturing process, which allows for improved power efficiency and thermal management. With a base clock speed of 2.4 GHz and the ability to boost up to 3.2 GHz, the E5-2620v3 is well-suited for handling demanding workloads .
Equipped with 6 cores and 12 threads, the Intel Xeon E5-2620v3 leverages Intel’s Hyper-Threading technology to enhance multitasking capabilities, allowing for more efficient processing of simultaneous tasks. The processor supports a maximum memory capacity of 768 GB, utilizing DDR4 memory, which provides higher bandwidth and lower power consumption compared to its predecessors. Additionally, the E5-2620v3 features advanced security and reliability features.
Intel Xeon E5-2620v3 Processor Specs
- Vertical Segment :Server
- Processor Number : E5-2620V3
- Lithography : 22 nm
- Total Cores : 6
- Total Threads : 12
- Max Turbo Frequency : 3.20 GHz
- Intel Turbo Boost Technology : 2.0 Frequency‡ 3.20 GHz
- Processor Base Frequency : 2.40 GHz
- Cache : 15 MB Intel Smart Cache
- Bus Speed : 8 GT/s
- # of QPI Links : 2
- TDP : 85 W
- Marketing Status : Discontinued
- Launch Date : Q3’14
- Servicing Status : End of Servicing Updates
- Embedded Options Available : Yes
- Use Conditions : Server/Enterprise
- Max Memory Size (dependent on memory type) : 768 GB
- Memory Types : DDR4 1600/1866
- Max # of Memory Channels : 4
- Max Memory Bandwidth : 59 GB/s
- Physical Address Extensions : 46-bit
- ECC Memory Supported ‡ : Yes
- Scalability : 2S
- PCI Express Revision : 3.0
- PCI Express Configurations ‡ : x4, x8, x16
- Max # of PCI Express Lanes : 40
- Sockets Supported : FCLGA2011
- Max CPU Configuration : 2
- TCASE : 72.6°C
Request for Quotation to buy Intel Xeon E5-2620v3 Processor
- Package Size : 52.5mm x 45mm
- Intel Turbo Boost Technology ‡ : 2.0
- Intel Hyper-Threading Technology ‡ : Yes
- Intel Transactional Synchronization Extensions : No
- Intel 64 ‡ : Yes
- Instruction Set : 64-bit
- Instruction Set Extensions Intel : AVX2
- Idle States : Yes
- Enhanced Intel SpeedStep Technology : Yes
- Intel Demand Based Switching : Yes
- Thermal Monitoring Technologies : Yes
- Intel Flex Memory Access : No
- Intel Identity Protection Technology ‡ : No
- Intel vPro Eligibility ‡ : Intel vPro Platform
- Intel AES New Instructions : Yes
- Secure Key : Yes
- Intel OS Guard : Yes
- Intel Trusted Execution Technology ‡ : Yes
- Execute Disable Bit ‡ : Yes
- Intel Virtualization Technology (VT-x) ‡ : Yes
- Intel Virtualization Technology for Directed I/O (VT-d) ‡ : Yes
- Intel VT-x with Extended Page Tables (EPT) ‡ : Yes
